Epoxy-activated Agarose for Ligand or Protein Coupling

Contact us

EPA-50

Epoxy-activated Agarose is a pre-activated affinity chromatography support for the immobilization of a variety of biomolecules that contain nucleophiles, such as hydroxyl, amino, or thiol groups. These groups couple to the epoxy groups on the support, which is then used for the purification of proteins, carbohydrates, or DNA.

Description

Epoxy-activated Agarose is a pre-activated affinity chromatography support for the immobilization of a variety of biomolecules that contain nucleophiles, such as hydroxyl, amino, or thiol groups. These groups couple to the epoxy groups on the support, which is then used for the purification of proteins, carbohydrates, or DNA.

Epoxy-activated Agarose CL-6B is based on highly cross-linked agarose 6% beads which have structural characteristics that result in superb physical strength, excellent flow properties, low backpressure, and an open pore structure. The open pore structure allows coupling of large ligands for the purification of large targets, including protein A for purification of monoclonal antibodies, and other ligands for purification of recombinant proteins, such as those containing maltose-binding protein and calmodulin. In addition, Epoxy-activated Agarose CL-6B allows operation at very high flow rates, resulting in increased throughput and rapid column cleaning between chromatography runs. It is supplied as a semi-dry powder (1 g of powder gives ~3.3 ml final drained medium) to significantly shorten conditioning time before ligand coupling.



Specifications

Chromatography technique

Affinity coupling

Application

Resin with a long hydrophilic spacer arm particular suitable for immobilization of small

Matrix

molecules as well as proteins

Active group

Highly cross-linked 6% beaded agarose

Active group density

>40 umol/ml drained medium

Spacer

1,4-bis(2,3-epoxypropoxy)butane (12 atom stable and uncharged ether hydrophilic linkage)

Group to be coupled

-OH, -NH2, or -SH

Bead geometry & size

Spherical 50 to 150 um

Bead mean diameter d50v

90 um

Linear flow velocity

<75 cm/h at 25 °C, HR 16/10 column, 5 cm bed height

Recommended linear flow rate

<30 cm/h

Pressure/flow specification

Base matrix 100-200 cm/h, pressure drop cm H2O/bed height = 15, bed height 10 cm, 5 cm i.d.

pH Stability working range

3 to 13

pH Stability cleaning in place (cip)

2 to 14

Chemical stability

Stable to commonly used aqueous solutions. Can be used with non-ionic detergents, denaturing solvents, e.g. 8 M urea and 6 M guanidine hydrochloride, Stable in organic solvents, e.g. 50% methylformamide and 50% dioxane.

Storage

2 to 8 °C



Name

Cat#

Description

Epoxy-activated Agarose

EPA-50

15g epoxy-activated agarose CL-6B (semi-dry resin swelling to 50 ml drained medium)

Epoxy-activated Agarose

EPA-250

75g epoxy-activated agarose CL-6B (semi-dry resin swelling to 250 ml drained medium)
