Read moreGeneral Description
I-5 Hi-Fi DNA HotStart Polymerase is an ultra-fast and high-fidelity DNA polymerase. It provides robust amplification of difficult templates including plasmids, BACS, genomic DNA, and lambda DNA. It allows the amplification of up to 8kb human genomic DNA and up to 21kb lambda DNA. It has an extension speed of 1 kb / 10-15 seconds depending on template type. This allows users to save time by speeding up PCR reactions and provides higher fidelity than Taq or Pfu. The enzyme contains a HotStart mechanism that inactivates the enzyme until it is heated. This allows users to setup PCR reactions at room temperature without worrying about primer dimers or non-specific preamplification.
Feature
• Fast – 4X faster than hot start Taq
• Robust – high inhibitor tolerance
• High yields – high efficiency
• Long PCR products
Source
E. coli
Applications
Hot Start PCR
Routine PCR
Fast PCR
High throughput PCR
Genotyping
Supplied with
5X Reaction Buffer (1ml), 50mM MgCl2 (1ml)
Supplied in (buffer description)
20mM Tris-HCl, 100mM KCl, 1mM DTT, 0.1mM EDTA, 200ug/ml BSA, 50% glycerol, 1X stabilizer, pH 8.0 @ 25 C
Storage Condition
-20ºC
Unit Definition
One unit is the amount of enzyme that incorporates 5 nmol of dNTPs into acid insoluble material in 15 minutes at 72°C.
Reference
Frey, B. and Suppman, B. (1995). BioChemica. 2, 34-35.
Chester, N. and Marshak, D.R. (1993). Analytical Biochemistry. 209, 284-290.
Shipping Condition
dry ice
User protocol
25 µl Reaction | 50 µl Reaction | Final Concentration | |
Instructions | |||
25 µl Reaction | 50 µl Reaction | Final Concentration | |
I-5 5X Buffer | 5 ul | 10 ul | 1X (see notes) |
10 µM Primer A | 1 µl | 2 µl | 400 µM |
10 µM Primer B | 1 µl | 2 µl | 400 µM |
Template DNA | as needed | as needed | see notes |
50mM MgCl2 | as needed | as needed | see notes |
I-5 Enzyme | 0.5 - 1 ul | 1 - 2 ul | |
Water (ddH2O) | up to 25 µl | up to 50 µl | |
Thermocycling Conditions | |||
3 Step PCR | |||
Step | Temperature | Time | |
Initial Denaturation | 98°C | 2 minutes | |
Denaturation | 98°C | 10 seconds | 25-35 cycles |
Annealing | 55°C - 68°C | 10-15 seconds | |
Extension | 72°C | 10-15 seconds / kb | |
Final Extension | 72°C | 1-5 minutes | |
4°C | Hold | ||
2 Step PCR (see notes) | |||
Step | Temperature | Time | |
Initial Denaturation | 98°C | 2 minutes | |
Denaturation | 98°C | 10-15 seconds | 25-35 cycles |
Combined Annealing & Extension | 72°C | 15-30 seconds / kb | |
Final Extension | 72°C | 1-5 minutes | |
4°C | Hold | ||
Notes | |||
Recommended DNA Template addition | |||
Genomic DNA | 50-250 ng | ||
Plasmid DNA | 1pg-10ng | ||
Viral DNA | 1pg-10ng | ||
Mg2+ | |||
The final concentration of Mg2+ in 1X I-5 PCR Master Mix is 1.5 mM | |||
Add additional Mg2+ as needed in 0.5 mM increments | |||
Suggested final Mg2+ concentration ranges from 2 mM to 4 mM | |||
2 Step PCR | |||
Use 2 Step PCR is recommended when the primer Tm values are >68°C | |||
PCR Product / Cloning | |||
The 2X I-5 PCR Master Mix results in PCR product with blunt ends | |||
Blunt-end cloning is recommended after PCR with this product | |||
For T/A-cloning, the PCR product should be purified before A-addition |
